VT5-49011A PVC

VT5-49011A PVC

VT5-49011A PVC

The VT5-49011A PVC fabric is a durable material crafted from PES HT yarn, featuring a total weight of 900g/m² and a 0.7mm thickness. It offers excellent performance with a tensile strength of 4000N/5CM (warp) and tear strength of 600N/5CM (warp). This robust fabric withstands temperatures from -30 to 70°C, has a mouldproof rating of 0 (highest), and is available in a 300cm width. With a 3-year warranty and ISO certifications, it is suitable for demanding industrial applications requiring strength and environmental resistance.

Category: Brand:
Width: 300cmVT5-49011A PVC · PES HT Yarn · 900g/m²
Key Features
• Tensile Strength Warp 4000N/5CM, Weft 3600N/5CM
• Tear Strength Warp 600N/5CM, Weft 500N/5CM
• Temperature Resistance -30~70°C
• Mouldproof Test 0 (Highest) – ASTM G 21–15 (2021)
• Warranty 3‑Year · ISO 9001 / 14001 / 45001
Specifications
Yarn PES HT
Width 300cm (DIN EN ISO 2286-1)
Thickness 0.7mm (DIN EN ISO 2286-3)
Total Weight 900g/m² ± 5% (DIN EN ISO 2286-2)
Roll Length 50 / 100 m/roll
Tensile Strength Warp 4000N/5CM, Weft 3600N/5CM (EN ISO 1421)
Tear Strength Warp 600N/5CM, Weft 500N/5CM (DIN 53363)
Adhesion >100N/5CM (EN ISO 2411)
Temperature Resistance -30~70°C (DIN EN 1876-1)
Flame Retardancy Customizable
Surface Treatment Top Side Acrylic, Back Side Glossy
Color Fastness 8 (EN ISO 105–B02)
Mouldproof Test 0 (Highest) – ASTM G 21–15 (2021)
Warranty 3‑Year
Certifications ISO 9001 / ISO 14001 / ISO 45001
